Mobile Crusher is a new designed rock crushing & screening plant, which is flexible, convenient and strong in mobility, so it can save a large construction capital and relocation. Raw Materials can be broken at the locale without being transported again and also can be moved with the promotional exploitation of the raw material, which saves a large number of transportation costs. We specialize in producing mobile crusher, screen, transportation, and other rock breaking and minerals processing equipment. On the basis of the professional technology, we optimize and introduce newly two large and three small series portable crushing and screening equipment. The mobile series is tracked crushing plant, and the portable series is portable type crushing plant. Each large series is divided into three series: rough, middle and fine crushing and screening mobile plant. Therefore, Portable crusher can fully adapt to the various mobile crushing and screening, which creates more new business opportunities for customers while reducing the cost of the production.

Application of Mobile Crusher:
The Mobile Crusher is applied to multistage crush large materials, and then screen the discharges according to their different specifications. The whole set plants is widely used to mine, building material, highway, rail way and hydropower industries, etc., finish crushing and screening operations at one time, produce required size and output for consumers.

Features of Mobile Crusher:
1. A complete plant; All the machines are installed on the trailer, saves the occupation space, enhances the working efficiency;
2. Strong flexibility; the mobility is very good, so it can extend with the raw material places or the construction place, and Mobile Crusher(Portable Crusher) can also make multiple matching, get to different product requirements.
3. High efficiency and saving energy.
4. Reliable working, convenient operation, and easy maintenance.

Model	Length L1(mm)	Width B1 (mm)	Height H1 (mm)	Max.Length L2(mm)	Max. Height H2(mm)	Max. Width B3(mm)	Height of Belt conveyor H3(mm)	Wheel	Weight （T）
MG938E69	12500	2450	4000	13200	4600	3100	2700	Paratactic double axles	42
MG1142E710	14000	2450	4800	15000	5800	3300	2700	Paratactic tri- axle	55
MG1349E912	15500	3000	4800	17000	5800	3500	3000	Paratactic quarter- axle	72

Model	Feeder Model	Jaw crusher Model		Belt Conveyor Model		Extended conveyor	Generator	Capacity (t/h)	Power
MG938E69	GZD380X960	PE600X900		B650X7000mm		adapting	adapting	70-150t/h	91.5KW
MG1142E710	GZD4200X1100	PE750X1060		B800X9000mm		adapting	adapting	80-200t/h	134KW
MG1349E912	GZD4900X1300	PE900X1200		B1000X11000mm		adapting	adapting	150-300t/h	146KW
