Rotary Kiln belongs to series of building equipment. It can be divided into cement kiln, metallurgy and chemical kiln, and lime kiln. Cement Kiln is mainly used in calcining cement clinker; it has wet method and dry method. Metallurgy and chemical kiln is mainly used in iron firing, Cr, Ni oxidation firing. It is mainly used for Kaolin calcination in the refractory factory, clinker and aluminium hydroxides calcination in aluminium factory. In the chemical kiln, it is mainly used in chrome ore calcination, chrome powder calcination and so on. Lime kiln can be called Active Lime Kiln, is mainly used for active lime and light burning dolomite calcination in iron plant and ferroalloy plant.

Specification(m)			φ2.8/2.5×44	φ3.2×52	φ3×48	φ3.2×50	φ3.2×50	φ3.3×50	φ3.5×54
Capacity(T/d)			300	600	700	1000	1200	1200	1500~1800
Gradient(%)			3.5	3.5	3.5	3.5	4	4	4
Support Number(Pc)			3	3	3	3	3	3	3
Round form of block			mechanism	mechanism And hydraulic	mechanism And hydraulic	hydraulic	hydraulic	hydraulic	hydraulic
Tube Speed		Main Drive(rev/min)	0.445-2.22	0.676-3.38	0.676-3.38	0.36-3.57	0.4-4.07	0.36-3.57	0.39-3.9
		Assistance drive (rev/h)	4.75	9.36	9.36	6.5	6.5	5.61	7.66
Main Drive	Power	Model	ZSN4-225-21	Z2-101	ZSN4-280-091B	ZSN4-280-091B	ZSN4-280-091B	ZSN4-280-11B	ZSN4-315-092
		Power(KW)	55	100	160	160	160	190	220
		Adjust Scope(rev/min)	~1500	~1500	~1500	~1500	~1500	~1500	~1000
		Rating Voltage(V)	440	440	440	440	440	440	440
	Reducer	Model	ZS145-1-I	ZS145-1-I	ZS145-1-I	ZSY450-40-V	ZSY450-40-V	ZSY450-40-V	NZS995-28VIBL
		ratio of speed	49.63	49.63	40	40	40	40	28
	Tachogenerator	Rating Power(K)	22	22	22	22	22	22	22
		Speed Range(rev/min)	0~2000	0~2000	0~2000	0~2000	0~2000	0~2000	0~2000
		maximum voltage(V)	110	110	110	110	110	110	110
Assistant Drive	Motor	Model	Y122M-4	Y160M-6	Y160M-4B	Y160M-4B	Y160M-4B	Y160M-4B	Y200L1-6
		Rating Power(KW)	4	7.5	15	11	11	15	18.5
		Speed Range (rev/min)	1440	970	1460	1460	1460	1460	970
		Rating Power(V)	380	380	380	380	380	380	380
	Reducer	Model	ZL35-16	ZL35-7-I	ZL35-7-I	ZSY160-31.5	ZSY355-31.5	ZSY160-31.5	ZSY355
		Total Ratio of Speed	40.44	14	31.5	31.5	31.5	31.5	45
Total weight (Not including firebrick) (T)			177	213	213	280.6	280.6	317	341

Any change of technical parameters, there is no further notice.
